GH3044 Nickel-Based Superalloy Sheet & Plate
Material Type：Ni-Cr based solid-solution strengthened wrought superalloy
Similar Grades：ЭИ686, ХН60ВТ, ВЖ90
Product Forms：Hot-rolled plate (4–14mm), Cold-rolled sheet (0.5–4mm)
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of gh3044 nickel-based superalloy sheet & plate in China. If you're going to wholesale high quality gh3044 nickel-based superalloy sheet & plate made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
Gnee Alloy GH3044 Plate: Key Global Export Markets
Our GH3044 sheets & plates are exported worldwide with complete MTC, customs clearance and dual-use material export documents:
Middle East (UAE, Saudi Arabia, Egypt): Stable demand for high-purity VIM-ESR sheets for gas turbine MRO and desalination thermal equipment
Western Europe (Germany, France): Premium industrial furnace & semiconductor thermal equipment OEM manufacturers
India: Fast-growing local aerospace fleet and gas turbine power plant construction demand
Southeast Asia (Vietnam, Thailand): Local thermal equipment processing factories & foundries
Contact us to customize a cost-effective solution for your project
GH3044 Nickel-Based Sheet & Plate Description
Gnee Alloy GH3044 Superalloy Sheet Description
GH3044 plate is a nickel-chromium-based, solid-solution-strengthened wrought superalloy (similar to UNS GH44 / XH60BT) designed for high-temperature structural components. It exhibits excellent oxidation resistance at temperatures up to 1000°C, maintains moderate strength below 900°C, and offers good cold formability, long-term microstructural stability, and excellent weldability.
Its chemical composition is based on nickel (balance), with chromium (20.0%–23.0%) and tungsten (10.0%–12.0%) serving as key strengthening elements; it also contains iron (≤3.0%–4.0%) and molybdenum (1.0%–1.5%). Room-temperature mechanical property requirements include a tensile strength of ≥1050 MPa, a yield strength of ≥600 MPa, and an elongation of ≥25%.
Equivalent grades for GH3044 plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| GH3044 | - | - | - | NA 11 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Contact our experts to recommend the right alloy for your project
high temperature GH3044 Plate Specification
| Parameter | GH3044 (GH44) Plate |
|---|---|
| Material Type | Ni-Cr based solid-solution strengthened wrought superalloy |
| Similar Grades | ЭИ686, ХН60ВТ, ВЖ90 |
| Applicable Standards | GJB 3317 (Hot-rolled), GJB 1952 (Cold-rolled), GB/T 14995 |
| Product Forms | Hot-rolled plate (4–14mm), Cold-rolled sheet (0.5–4mm) |
| Strengthening Mechanism | Solid-solution strengthening (W 13–16%, minor Al and Ti) |
| Service Temperature | Long-term service up to 900°C |
| Oxidation Resistance | Excellent; surface forms protective oxide scale |
| Weldability | TIG, spot, seam, brazing; weldable to 1Cr18Ni9Ti, GH1140, GH3030, GH3039 |
| Magnetic Properties | Non-magnetic |
Key Properties of GH3044 Alloy Plate
Chemical composition of GH3044 Sheet (wt%)
| Element | Content (wt%) | Role |
|---|---|---|
| Nickel (Ni) | Balance | Matrix element - provides high-temperature stability |
| Chromium (Cr) | 23.5 – 26.5 | Core oxidation resistance - forms Cr₂O₃ protective film |
| Tungsten (W) | 13.0 – 16.0 | Core solid-solution strengthening element - enhances high-temperature strength |
| Iron (Fe) | ≤ 4.00 | Controlled impurity |
| Molybdenum (Mo) | ≤ 1.50 | Secondary solid-solution strengthening |
| Aluminum (Al) | ≤ 0.50 | Oxidation resistance |
| Titanium (Ti) | 0.30 – 0.70 | Carbide stabilization |
| Carbon (C) | ≤ 0.10 | Grain boundary strengthening control |
| Manganese (Mn) | ≤ 0.50 | Deoxidation |
| Silicon (Si) | ≤ 0.80 | Deoxidation |
| Phosphorus (P) | ≤ 0.013 | Strictly controlled - ensures toughness and weldability |
| Sulfur (S) | ≤ 0.013 | Strictly controlled - ensures hot workability and weldability |
| Copper (Cu) | ≤ 0.07 (cold-rolled) / ≤ 0.07 (hot-rolled) | Impurity element control |
Physical Properties of GH3044 Alloy Plate
| Property | Value | Unit |
|---|---|---|
| Density | 8.89 | g/cm³ |
| Melting Range | 1352 – 1375 | °C |
| Thermal Conductivity (100°C) | 11.7 | W/(m·K) |
| Specific Heat | 440 | J/(kg·K) |
| Elastic Modulus (RT) | ~203 | GPa |
| CTE (20–100°C) | 12.25 × 10⁻⁶ | /°C |
| Magnetic Properties | Non-magnetic | - |
Click to download the GH3044 alloy PDF file now
GH3044 Plate Mechanical Properties – Solution Treated Condition
| Product Form | Thickness | UTS (MPa) | YS 0.2% (MPa) | Elongation δ5 (%) | Hardness (HBS) |
|---|---|---|---|---|---|
| Cold-rolled sheet | 0.5 – 4mm | ≥ 735 | - | ≥ 40 | - |
| Hot-rolled plate | 4 – 14mm | ≥ 735 | - | ≥ 40 | - |
| Strip | 0.1 – 0.8mm | ≥ 735 | - | ≥ 40 | - |
Contact us for information on our GH3044 production process
GH3044 Plate heat treatment process
| Product Form | Heat Treatment | Soaking Time | Cooling |
|---|---|---|---|
| Cold-rolled sheet (δ ≤ 3mm) | 1120–1160°C | 8–12 min | Air Cool (AC) |
| Cold-rolled sheet (δ 3–5mm) | 1120–1160°C | 12–16 min | Air Cool (AC) |
| Hot-rolled plate | 1120–1160°C | - | Air Cool (AC) |
| Hot-rolled strip | 1120–1160°C | - | Air Cool (AC) |
Click to view the GH3044 heat treatment process curve
Comprehensive Manufacturing Process for GH3044 Plates
We employ a fully closed-loop production process to ensure the material possesses superior flatness, uniform grain structure, and freedom from hidden defects, meeting the demands of high-temperature service:
VIM + ESR Dual-Melting Process (Core Quality Control)
We utilize a combination of Vacuum Induction Melting (VIM) and Electroslag Remelting (ESR). This process eliminates impurity segregation, reduces internal shrinkage cavities and micro-cracks, significantly enhances material uniformity, and effectively prevents cracking during long-term high-temperature operation. All aerospace-grade GH3044 plates are produced using this dual-melting method.
Multi-pass Cold Rolling
For thin plates (0.05mm–3.0mm): Repeated cold rolling combined with intermediate solution annealing is used to eliminate internal rolling stresses, achieving ultra-thin, uniform thickness and a smooth surface finish.
For thick plates (4.0mm–12.0mm): Hot rolling is employed, followed by pickling to remove surface scale.
Solution Heat Treatment (1150°C – 1200°C)
High-temperature solution treatment followed by rapid water quenching ensures full solid solution of alloying elements, thereby maximizing ductility, weldability, and high-temperature oxidation resistance.
Precision Leveling and Custom Cutting
High-precision leveling equipment ensures excellent flatness in the finished plates. Laser cutting based on customer drawings allows for custom-sized blanks that require no secondary grinding.
Comprehensive Quality and Non-Destructive Testing (NDT)
Prior to packaging and shipment, the material undergoes 100% inspection for surface appearance, dimensional tolerances, and metallographic grain structure, as well as ultrasonic flaw detection.
Contact us for information on our GH3044 production process
Standard Surface Finishes for GH3044 Sheet & Plate
| Surface Grade | Production Craft & Appearance | Core Application Scenarios |
|---|---|---|
| 2B Finish (Cold Rolled, Annealed & Pickled) | Matte grey uniform surface, pickled after cold rolling & annealing, cost-effective mainstream export grade | Aerospace combustion chamber liners, general thermal shield parts; excellent forming & welding performance, easy secondary machining |
| BA Bright Annealed | Annealed under inert protective atmosphere, mirror bright oxide-free surface, high surface cleanliness | Precision thin sheets for high-standard aerospace thermal shielding components, ultra-clean lab equipment parts |
| No.1 Hot Rolled Annealed & Pickled | Dark matte surface after hot rolling & pickling, for heavy gauge plates over 4mm | Large industrial furnace lining plates, bulk thermal shielding panels, low-precision high-temperature structural parts |
| Sand Blasted / Shot Peened | Uniform rough matte surface via sandblasting treatment | Substrate for thermal barrier coating (TBC); enhanced coating adhesion strength for gas turbine hot components |
Full Size Specifications of GH3044 Sheet & Plate
| Parameter | Specification |
|---|---|
| Thickness Range | |
| Cold Rolled Thin Sheet | 0.05 mm ~ 3.0 mm |
| Hot Rolled Thick Plate | 4.0 mm ~ 12.0 mm |
| Standard Width Options | 1000 mm / 1219 mm / 1500 mm (custom slitting width available on request) |
| Compliance Standards | |
| Domestic Standard | GB/T 14992 |
| International Reference Standard | ASTM B435 (comparable to Hastelloy X) |
| Custom Services | Custom length cutting, laser blanking, surface polishing, special tolerance control all supported |
Contact us to customize GH3044 products to your project's dimensions
Core Application Fields of GH3044 Alloy Sheet & Plate
| Industry / Application Area | Specific Components / Equipment |
|---|---|
| Aerospace Industry (Largest End-Use Market) | Combustion chamber liners, jet engine flame tubes, afterburner heat shielding baffles; Auxiliary thermal shielding components for military & civil aircraft engine hot sections |
| Power Gas Turbine Equipment | Gas turbine transition pieces, high-temperature partition shielding plates; Long-cycle thermal cycle parts working under 900–1100°C continuous operation |
| Industrial Furnace & Heat Treatment Equipment | Vacuum furnace lining panels, furnace fixture plates, high-temperature oven heat shields; Repeated heating & cooling furnace structural components with thermal shock resistance demand |
| High-Temperature Heat Exchangers | Heat exchange plates & shells serving in continuous high-temperature oxidizing flue gas environments |
| Petrochemical High-Temperature Equipment | Thermal shielding liners for high-temperature reactors, anti-oxidation partition plates inside high-heat pipelines |
Testing Methods for GH3044 Sheets
The thickness range for GH3044 plates is 4–14 mm. The plates are supplied in a solution-treated, pickled, leveled, and edge-trimmed condition.
| Test Item | Test Method | Reference Standard / Notes |
|---|---|---|
| Chemical Composition | OES or Chemical Analysis | Per standard requirement |
| Room-Temperature Tensile Test | Round specimen or non-standard round specimen | Thickness ≥7mm uses round specimen; thickness <7mm may use non-standard round specimen (supplier provides measured data only, not used as acceptance criteria) |
| High-Temperature Tensile Test | High-temperature tensile testing machine | GB/T 4338 / per agreement |
| Hardness Test | Brinell Hardness (HB) | Per standard requirement |
| Grain Size Examination | Metallographic method | Per standard requirement |
| Ultrasonic Testing (UT) | Ultrasonic flaw detector | Per agreement (when specified by purchaser) |
| Penetrant Testing (PT) | Penetrant inspection | As specified |
| Dimensional Inspection | Calipers, micrometers | Per standard requirement |
| Surface Quality | Visual inspection | Per standard requirement |
| High-Temperature Creep Rupture Test | High-temperature creep testing machine | Per agreement (when specified by purchaser) |
Nickel Based Alloy GH3044 Packaging
GNEE Group Alloy GH3044 Product Packaging
Contact us to select your preferred packaging and shipping method
About Gnee Steel
Please provide the following information when submitting your inquiry to receive immediate support:
Required specifications: thickness, width, length, and surface condition
Order quantity and application area (e.g., aerospace, gas turbines, industrial furnaces, etc.)
Destination country and special certification requirements (e.g., MTC 3.2, aerospace grade)
Free small samples available for performance testing prior to bulk orders
Digital technical datasheet for GH3044 provided immediately upon inquiry submission
Flexible batch support: accommodating both small-scale trial orders and large-scale production orders
Our Factory Strengths for GH3044 Sheet & Plate
Complete integrated flat alloy production line: Independent smelting, rolling, heat treatment, leveling and finishing workshops, fully control quality & delivery cycle
Mandatory VIM+ESR double melting for aerospace-grade sheets, meets international aviation material standards
Full customization service: Custom thickness, width, length, surface finish, laser cutting blanking per customer drawings
Multi-stage strict quality inspection: Raw material test → mid-process metallurgical inspection → finished product NDT & dimension test → final surface inspection before shipment
18 years high-temperature alloy export experience, proficient in international logistics, customs clearance and dual-use material export procedures
Free technical support: Provide alloy comparison reports, high-temperature performance data and processing guidance upon inquiry
Gnee Alloy GH3044 certificate
FAQ
Q1: Why choose GH3044 over GH4169 (718) for service at 900°C?
A: This is a classic selection error. While 718 is stronger at 600°C, it reaches its over-aging threshold at 750°C and softens rapidly. GH3044 is the "Red Zone Hero" because its strength comes from solid-solution elements (W, Mo) that do not dissolve at extreme heat, providing superior Structural Integrity.
Q2: Is GH3044 easy to weld for complex assemblies?
A: Absolutely. One of its greatest commercial advantages is its Superior Weldability. It is highly ductile and does not require complex post-weld aging heat treatments, significantly reducing your Custom Fabrication time and cost.
Q3: Can GH3044 handle sulfur-containing combustion gases?
A: Yes. Its high Chromium content (23.5-26.5%) provides a robust defense against oxidation and corrosion in various combustion atmospheres, making it ideal for afterburner manifolds.
Q4: Do you offer trial orders for prototype liners?
A: Yes. As a Reliable Supplier, we support aerospace and energy innovation. We offer Flexible MOQs on our in-stock inventory of standard gauges.
