Monel 500
• Exceptionally good dimensional stability
• Resistant to a sour-gas environment
• Excellent corrosion resistance together with increased strength and hardness of that of Alloy 400
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Monel 500 Description
GNEE STEEL Monel 500 video
Monel 500 is commonly known as monel K500. Monel K500 actually has the same corrosion resistance as Monel 400, but has higher mechanical strength and hardness than 400. It also has better hot corrosion resistance and long-term organizational stability. However, the plasticity is slightly lower than that of Monel K500. Compared with Monel400, this alloy contains a mass fraction of 2.3%~3.15% aluminum AL and 0.3%~1.00% titanium Ti. The amount added is different in different places.
|
Form |
Standard |
|---|---|
|
Metal Type |
UNS N05500 |
|
Bar |
ASTM B865 QQ-N-286 |
|
Wire |
AMS4676 |
|
Sheet |
ASTM B865 QQ-N-286 |
|
Plate |
ASTM B865 QQ-N-286 |
|
Fitting |
|
|
Forging |
QQ-N-286 Din 17754 |
|
Weld Wire |
FM 60 ERNiCu-7 |
|
Weld Electrode |
FM 190 ENiCu-7 Din 17753 |
|
Din |
2.4375 |
GNEE Monel 500 information
|
Monel 500 FORM |
SIZE RANGE FROM |
SIZE RANGE TO |
|
Alloy k-500 pipe |
0.5 in |
8 in |
|
Alloy k-500 tube |
12 mm |
260 mm |
|
Alloy k-500 pipe fittings |
0.5 in |
8 in |
|
Alloy k-500 flanges |
0.5 in |
8 in |
GNEE Monel 500 Application
Typical applications for Monel are valves and pumps; pumps and drive shafts; electrical and electronic components; crude oil stills, boiler feed water heaters, marine fixtures and fasteners; gasoline and water tanks; gasoline drums; springs; chemical processing equipment ; Process vessels and piping; heat exchangers; metal musical instruments; degassing heaters; musical instruments; refrigerators; film processing; kitchen sinks; roofs; and eyeglass frames. Monel alloy is available in pipes, pipe fittings, plates, strips, round rods, and strips.
GNEE Monel 500 Feature
In addition to its excellent mechanical properties such as high strength, corrosion resistance, and non-magnetic properties, Monel K500 alloy also has the same corrosion resistance as Monel 400. It can be used as a pump shaft material and is suitable for working in harsh geological mining conditions of high-sulfur and high-wax oil layers. Since this alloy has no plastic-to-brittle transition temperature, it is very suitable for various low-temperature equipment.
