UNS S21800 NITRONIC 60 Sheet Plate
video

UNS S21800 NITRONIC 60 Sheet Plate

Nitronic ® 60 is an austenitic stainless steel alloy that is good in many areas. The alloy has good mechanical properties at high temperatures up to 980 ° C. Corrosion properties are intermediate between 304 and 316, but the yield is double. The addition of silicon and manganese makes the material resistant to abrasion and wear. Nitronic ® 60 is often used for fasteners and valves.
Send Inquiry
Chat Now

As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.

Product Introduction
NITRONIC® 60 Stainless Sheet

Nitronic 60 stainless steel provides a significantly lower cost solution to wear and galling problems than cobalt bearing and high nickel alloys. It is a high strength austenitic stainless steel strengthened by nitrogen. It differs from more familiar austenitic stainless steels in containing 8% manganese and 4% silicon. The alloy has better uniform corrosion resistance than type 304 in most media. The chloride pitting resistance is superior to type 316, with room temperature yield strength nearly twice that of 304 and 316. In addition Nitronic 60 has excellent high temperature oxidation resistance and good low temperature impact resistance.



NITRONIC® 60 SS Sheet/Plate

Chemistry OF NITRONIC® 60 Sheet/Plate

Chemical Requirements



Ni

Cr

Mn

Si

N

Mo

C

Max

9.00

18.00

9.00

4.5

0.18

0.75

0.10

Min

8.00

16.00

7.00

3.5

0.08







Tensile Data OF Alloy 218 SS Plate

Mechanical Property Requirements Under 0.5"



Ultimate Tensile

Yield Strength (0.2% OS)

Elong. in 4D

R/A

Hardness

Min

105 KSi

55 KSi

35%

55%



Max



Min

724 MPa

379 MPa



Max





Mechanical Property Requirements Over 0.5"



Ultimate Tensile

Yield Strength (0.2% OS)

Elong.

R/A

Hardness

Min

95 KSi

50 KSi

35%

55%



Max



Min

655 MPa

345 MPa



Max



stainless sheet

Nitronic 60 is truly an all purpose metal. This fully austenitic alloy was originally designed as a temperature alloy, and subsequently has good high temperature properties for temperatures around 1800ºF. The oxidation resistance of Nitronic 60 is similar to Type 309 S.S., and far superior to Type 304S.S. This grade is best known for its wear and galling resistance.



Nitronic® 60 is also highly resistant to corrosion, with a resistance somewhere between 304 and 316 stainless steel, while having nearly double the yield strength of both these steels. While 316 stainless steel may be somewhat more corrosion resistant, Nitronic® 60 has superior resistance to chloride pitting, as well as stress and crevice corrosion, making it more suitable for marine applications than 316. Additionally, its oxidation resistance is comparable to 309 stainless steel and it has a low-temperature impact.



Customer Visit



GNEE STEEL

The Group adheres to the tenet of "one-stop service, making choices easier" and adheres to the business philosophy of "successful customers, happy employees; embracing change, the most important thing is action", and continues to meet the different needs of global customers in the field of the world's steel supply chain need. A professional sales team provides customers with first-class services; a strict procurement and quality inspection team carefully selects high-quality raw materials; an advanced science and technology team improves production and reduces costs for customers; an excellent design and processing team strives for excellence. Considerate shipping and logistics team to protect product transportation.



FAQ



Q: What product information must I provide before purchasing?
A:Please provide the grade, width, thickness, surface treatment requirements and the quantity you require.
Q: What shipping ports are there?
A:We usually ship from Shanghai, Tianjin, Qingdao and Ningbo ports.
Q: What are your payment terms?
A:30% T/T in advance, 70% balance before shipment or based on copy of bill of lading or L/C at sight.
Q: What about product pricing information?
A:Prices vary due to regular changes in raw material prices.
Q: Can I send samples?
A:Of course, we provide free samples and express delivery to customers all over the world.


Hot Tags: UNS S21800 NITRONIC 60 Sheet Plate, China UNS S21800 NITRONIC 60 Sheet Plate suppliers, high temperature corrosion resistant alloy, , , , Inconel Alloy
