As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of astm ah36 ccs ship steel plate , mechanical properties lr shipbuilding plate in China. If you're going to wholesale high quality astm ah36 ccs ship steel plate , mechanical properties lr shipbuilding plate made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
ASTM AH36 CCS Ship Steel Plate , Mechanical Properties LR Shipbuilding Plate
Description
| Width: | 1000-2000mm | Length: | 2000-12000mm |
|---|---|---|---|
| Thickness: | 0.5-100mm | Grade: | AH36 |
| Class: | CCS LR | ||
| High Light: |
shipping plate,marine steel plate |
||
ASTM AH36 CCS Plate AH36 Steel Mechanical Properties LR AH36 Shipbuilding Plate
CCS Grade AH36 shipbuilding steel plate owned higher yield strength and tensile strength.Shipbuilding steel plate CCS Grade AH36 is the Hull structural steel,with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.
■ Full Data
Technical Requirements & Additional Services:
♦ High tension test
♦ Z-Test (Z15,Z25,Z35)
♦ Low temperature impacting test
♦ Ultrasonic test under ASTM A435,A577,A578
♦ Cetificated by ABS,LR,GL,BV,DNV,KR,NK,CCS,RINA
♦ Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
♦ Shot blasting and Painting,Cutting and welding as per end user's demands
■ Techicals
►Mechnical property for CCS Grade AH36 shipbuilding structual steel:
| Yield strength (≥Mpa) | Tensile strength (Mpa) | Elongation in ≥,% | |
| 355 | 490-620 | 200mm | 50mm |
| 19 | 22 | ||
►Chemical composition for CCS Grade AH36 ship steel (Heat Analysis Max%)
| Main chemical elements composition of CCS Grade AH36 | ||||||
| C | Si | Mn | P | S | Al (acid) min. | Nb |
| 0.18 | 0.10-0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02-0.05 |
| V | Ti | Cu | Cr | Ni | Mo | |
| 0.05-0.10 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 | |
AH36,CCS/AH36|CCS GRADE AH36,CCS AH36 STEEL PLATE
Gangsteel is specialized in supplying CCS high strength steel plate in CCS Grade AH36. For more information of Grade AH36 steel plate, please check them in following:
| CCS/AH36 high Strength Chemical Composition in Tempering and Quenching | |||||||
| Grade | The Element Max (%) | ||||||
| C | Si | Mn | P | S | Al | N | |
| CCS/AH36 | 0.18 | 0.1-0.50 | 0.90-1.6 | 0.035 | 0.035 | 0.015 | |
| Nb | V | Ti | Cu | Cr | Ni | Mo | |
| 0.02-0.05 | 0.05-0.10 | 0.02 | 0.35 | 0.2 | 0.4 | 0.08 | |
Crack Sensitivity: Pcm = (C+Si/30+Mn/20+Cu/20+Ni/60+Cr/20+Mo/15+V/10+5B)%
Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%
| CCS/AH36 high strength property in tempering and quenching | |||||||
| Grade | Mechanical Property | Charpy V Impact Test | |||||
| Thickness | Yield | Tensile | Elongation | Degree | Energy 1 | Energy 2 | |
| CCS/AH36 | mm | Min Mpa | Mpa | Min % | 0 | J | J |
| t≤50 | 355 | 490-620 | 21% | 24 | 34 | ||
| 50＜t≤70 | 355 | 490-620 | 21% | 27 | 41 | ||
| 70＜t≤100 | 355 | 490-620 | 21% | 34 | 50 | ||
| Note: Energy 1 is transverse impact test, Energy 2 is longitudinal | |||||||
Boiler steel plates| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate
| Equivalent steel grade of CCS/AH36 | |||||||
| DNV | GL | LR | BV | ABS | NK | KR | RINA |
| NV A36 | GL-A36 | LR/AH36 | BV/AH36 | ABS/A36 | K A36 | R A36 | RI/A36 |
If you need more stock steel plates in shipbuilding steel plate, please click warehouse sizes.
Related steel grades: CCS/DH36, CCS/EH36, CCS/FH36, CCS/AH32
| CCS Steel Plate Grade | ||||
| General Strength | CCS/A | CCS/B | CCS/D | CCS/E |
| High Strength | CCS/A32 | CCS/D32 | CCS/E32 | CCS/F32 |
| CCS/A36 | CCS/D36 | CCS/E36 | CCS/F36 | |
| CCS/A40 | CCS/D40 | CCS/E40 | CCS/F40 | |
| Extra Strength | CCS/A420 | CCS/D420 | CCS/E420 | CCS/F420 |
| CCS/A460 | CCS/D460 | CCS/E460 | CCS/F460 | |
| CCS/A500 | CCS/D500 | CCS/E500 | CCS/F500 | |
| CCS/A550 | CCS/D550 | CCS/E550 | CCS/F550 | |
| CCS/A620 | CCS/D620 | CCS/E620 | CCS/F620 | |
| CCS/A690 | CCS/D690 | CCS/E690 | CCS/F690 | |
