Inconel 718 alloy strip performance information
INCONEL alloy 718 strip is an age-hardenable nickel-chromium-niobium-molybdenum alloy strip that combines high strength, corrosion resistance, and good fabrication properties. INCONEL alloy 718 strip exhibits high tensile strength, yield strength, and creep-rupture properties at temperatures up to 1200°F (650°C).
Gnee Steel
What is the hardness of 718 alloy?
The hardness in the solution-treated condition is approximately HRc 20-25, which increases to approximately HRc 36-44 after aging. ATI 718 alloy exhibits good oxidation resistance up to approximately 1,800°F (982°C). The alloy also exhibits good corrosion resistance to a wide range of corrosive media, including resistance to stress corrosion cracking.
Inconel 718 Alloy Strip Chemical Compositions
The chemical components of grade Inconel 718 strip is summarized in the following table:
| Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Ti |
| Inconel 718 | ASTM B 670, ASTM B 906, SAE AMS 5596 | ≤0.08 | ≤0.35 | ≤0.35 | ≤0.015 | ≤0.015 | 17.00-21.00 | 50.0-55.0 | 0.65-1.15 |
Inconel 718 Alloy Strip Mechanical Properties
| Element | Yield Strength (0.2%Offset) | Melting Point | Density | Tensile Strength | Elongation |
| Inconel® 718 | MPa – 550 | 1390 °C (2540 °F) | 8.28 g/cm3 | MPa – 910 | Min 25 % |
Inconel 718 Strip Physical Properties
1. Density: 0.296 lb/in³ (8.28 g/cm³)
2. Modulus of Elasticity (E):
At 20°C (70°F): 29 x 10³ ksi (200 GPa)
3. Modulus of Rigidity (G):
At 20°C (70°F): 11.6 x 10³ ksi (80 GPa)
4. Coefficient of Expansion:
7.7 µin/in.-°F (70°F to 600°F)
13.9 µm/m-°C (20°C to 538°C)
5. Resistivity: 47.5 µΩ.in (121 µΩ.cm)
6. Thermal Conductivity: 79 Btu-in/ft²hr-°F (11.4 W/m·K)
What is the standard seaworthy packaging for Inconel 718 alloy strip?
Standard export seaworthy packaging:
Waterproof paper wrap + PVC film + strapping + wooden pallet or crate.
Customized packaging available upon request (branding or other content can be printed on the packaging).
Other special packaging options available upon request.
We offer both "wall-to-wall" and "day-to-day" packaging.
International express delivery: DHL/UPS/FEDEX/EMS, as well as our own express delivery lines.
Air or sea freight.
Gnee Steel specializes in the production and sale of various nickel-based alloys, including Nickel 201, Nickel 202, Hastelloy C-276, Hastelloy C-22, Hastelloy B, Hastelloy C-4, Inconel Alloy 600, Inconel 625, Inconel 718, Inconel X-750, Incoloy Alloy 800, Incoloy 800H/HT, Incoloy 825, Monel Alloy 400, Monel K500, and high-temperature alloys. Gnee Steel's products are widely used in aerospace, chemical, electric power, automotive, and nuclear energy applications. We also offer customized alloy solutions tailored to customer needs. For alloy pricing inquiries or customized alloy solutions, please contact us for a quote at ss@gneesteel.com.
