What are the advantages of Hastelloy C-276?

What Is Hastelloy C-276?



Alloy C-276 (UNS N10276, EN W.Nr 2.4819) is a wrought nickel-chromium-molybdenum alloy with a tungsten addition, covered for plate, sheet and strip by ASTM B575 / ASME SB575, for seamless pipe and tube by ASTM B622, and for welded pipe and tube by ASTM B619 / B626. It is the most widely specified alloy of the C family because its balanced molybdenum plus tungsten content gives useful resistance to both reducing acids (hydrochloric, sulfuric, phosphoric) and oxidizing media (wet chlorine, hypochlorite, ferric salts), a combination most stainless steels and even Alloy 825 cannot match.

Contact now



Hastelloy C-276 - High Performance Nickel AlloysAlloy C-276 - The Standard for Corrosion Resistance



Hastelloy C-276 Chemical Composition (ASTM B575)



Element Range / Limit (%) Role
Nickel (Ni) Balance (remainder) Base metal; austenitic structure and SCC resistance.
Chromium (Cr) 14.5 – 16.5 Oxidation resistance; passivity in oxidizing media.
Molybdenum (Mo) 15.0 – 17.0 Resistance to reducing acids and localized attack.
Tungsten (W) 3.0 – 4.5 Reinforces reducing-acid and crevice resistance.
Iron (Fe) 4.0 – 7.0 Structural balance.
Cobalt (Co), max 2.5 Impurity limit - NOT a main alloying element.
Manganese (Mn), max 1.0 Deoxidizer.
Carbon (C), max 0.01 Kept low to limit carbide precipitation in welding.
Silicon (Si), max 0.08 Deoxidizer.
Phosphorus (P), max 0.04 Impurity control.
Sulfur (S), max 0.03 Impurity control.
Vanadium (V), max 0.35 Impurity control.



Hastelloy C-276 Properties



The typical mechanical properties of Hastelloy C-276:

Annealed
Approx. tensile strength <1050 N/mm² <152 ksi
Approx. operating temperature depending on load** and environment -200 to +400 °C -330 to +750 °F



Spring Temper
Approx. tensile strength 1300 – 1700 N/mm² 189 – 247 ksi
Approx. operating temperature depending on load** and environment -200 to +400 °C -330 to +750 °F



Verified Advantages of Hastelloy Alloy



1.Broad-spectrum corrosion resistance

C-276 resists pitting, crevice corrosion and stress-corrosion cracking in chloride environments, and holds up in wet chlorine, hypochlorite and chlorine dioxide service up to practical concentration/temperature limits. It remains intact where 316L and even super-austenitic stainless steels pit or crack.



2.Performance in both oxidizing and reducing media

The molybdenum-tungsten combination carries reducing-acid resistance while chromium provides passivity in oxidizing streams - the same heat exchanger can face a reducing process stream on one side and an oxidizing stream on the other.



3.High-temperature capability

Useful oxidation resistance to roughly 1038 °C (1900 °F) in oxidizing atmospheres, with good hot strength for furnace and flue-gas components. Note the sigma-phase caution below.



4.Essentially non-magnetic

The fully austenitic structure keeps magnetic permeability near 1.002, which matters for instrumentation housings, EMC-sensitive assemblies and rotating equipment.



5.Weldable and formable when controlled

GTAW with ERNiCrMo-4 filler is routine; cold forming and shearing are practical. The alloy is supplied in annealed condition and can be hot or cold worked with appropriate force ratings.



6.Regulatory and code acceptance

Listed in NACE MR0175 / ISO 15156-3 for sour oil and gas service and accepted under ASME B31.3, B31.1 and pressure-vessel codes in plate, pipe and fitting forms.



When Should You Choose C-276 (and When Not)?



Choose Alloy C-276 when… Consider an alternative when…
Hydrochloric or sulfuric acid at elevated temperature/concentration defeats 316L and Alloy 825. Media are mildly corrosive and 316L/317L pass testing - pay less.
Wet chlorine, hypochlorite, chlorine dioxide, or chloride pitting/SCC environments. Service is purely oxidizing (hot concentrated nitric acid) - C-276 chromium is limited; higher-Cr grades may fit better.
Flue-gas desulfurization, chemical reactors, pulp bleaching, pharmaceutical reactors. Budget-driven projects with no corrosion test data - qualify first.
Requirement for non-magnetic, code-listed, sour-service material. Temperature is continuously in the 650–1090 °C range - verify phase stability.



Hastelloy C276 Alloy: Special Metal AlloysBenefits of Hastelloy C276 Fittings

Request Quotation

FAQ:

Is Hastelloy better than stainless steel?

Hastelloy's superior corrosion resistance and strength are ideal for environments involving extreme temperatures, pressures, and corrosive materials. On the other hand, stainless steel provides a cost-effective solution with adequate performance for many standard applications.



Is Hastelloy better than inconel?

For instance, Hastelloy is more suitable for acidic environments, while Inconel is better for oxidizing environments. This is because Hastelloy has a higher molybdenum content, which supplies more resistance in non-oxidizing and acidic environments.



Is Hastelloy magnetic?

No, Hastelloy is generally non-magnetic, meaning it does not attract magnets or create strong magnetic fields. Because it is a nickel-base superalloy, its special atomic structure stops it from acting like iron or steel.
