What are the physical properties of Inconel 718?
What are the physical properties of Inconel 718?
Inconel 718 is a high-strength, corrosion-resistant nickel-chromium-iron-based superalloy (containing 50-55% nickel and 17-21% chromium), renowned for its excellent stability at temperatures up to 700°C (1300°F). Its key physical properties include a density of approximately 8.19-8.23 g/cm³ (0.296 lb/in²), a melting point range of 1260-1336°C (2300-2440°F), and a magnetic permeability of less than 1.002. It exhibits high tensile strength, good ductility, and excellent resistance to post-weld cracking.
What type of metal is Inconel 718?
Nickel-chromium alloy
Inconel 718 is a precipitation-hardening nickel-chromium alloy containing significant amounts of iron, niobium, and molybdenum, as well as small amounts of aluminum and titanium.
Inconel 718 Alloy
Inconel 718 is a precipitation-hardening nickel-chromium alloy containing significant amounts of iron, niobium, and molybdenum, and minor amounts of aluminum and titanium. It combines corrosion resistance with high strength and excellent weldability, including resistance to post-weld cracking. This alloy exhibits excellent creep rupture strength at temperatures up to 700°C (1300°F). It is widely used in gas turbines, rocket engines, spacecraft, nuclear reactors, pumps, and tools.
Chemical Composition of Inconel 718
Typical chemical analysis of Inconel 718.
|
Element
|
Percentage |
| Carbon |
0.08 max |
| Manganese |
0.35 max |
| Phosphorus |
0.015 max |
| Sulfur |
0.015 max |
| Silicon |
0.35 max |
| Chromium |
17-21 |
| Nickel |
50-55 |
| Molybdenum |
2.80-3.30 |
| Columbium |
4.75-5.50 |
| Titanium |
0.65-1.15 |
| Aluminum |
0.20-0.80 |
| Cobalt |
1.00 max |
| Boron |
0.006 max |
| Copper |
0.30 max |
| Tantalum |
0.05 max |
| Iron |
Balance |
Corrosion Resistance and Oxidation Resistance of Inconel 718
In the atmospheres encountered during the operation of jet engines and gas turbines, Inconel 718 exhibits good oxidation and corrosion resistance within the effective strength range of the alloy.
Physical Properties of Inconel 718 Alloy
The typical physical properties of Inconel 718 are summarized in the table below.
|
Solution Treated |
Solution Treated and Aged |
|
| Density |
0.296 lb/in3 (8.192 g/cm3) |
0.297 lb/in3 (8.22 g/cm3) |
| Specific Gravity |
8.19 |
8.22 |
| Melting Range |
2500-2600°F |
1370-1430°C |
Thermal Conductivity of Inconel 718
The table below shows the thermal conductivity of Inconel 718 at different temperatures.
|
Temperature Range |
Co-Efficients |
||
|
°C |
°F |
W/m.K |
Btu.ft/ft2.hr.°F |
|
0-100 |
532-212 |
6.5 |
11.2 |
Mechanical properties of Alloy 718
As shown in the following data, precipitation heat treatment can significantly improve the room temperature strength of Inconel 718 alloy. These values are performance specifications for sheet, strip, and plate materials as defined in AMS 5596 and AMS 5597 standards.
|
Yield Strength |
Ultimate Tensile Strength |
Elongation |
|
|
Sheet and strip |
80,000 psi (550 MPa) |
140,000 psi (965 MPa) |
30 (min) |
|
Plate |
105,000 psi (725 MPa) |
150,000 psi (1,035 MPa) |
30 (min) |
Solution treatment followed by precipitation heat treatment.
|
Yield Strength |
Ultimate Tensile Strength |
Elongation |
|
150,000 (1,035 MPa) |
180,000 psi (1,240 MPa) |
12 (min) |
