825 Incoloy Alloy Ship Round Bars
· Excellent resistance to reducing and oxidizing acids
· Good resistance to stress corrosion cracking
· Satisfactory resistance to localized corrosion, such as pitting and crevice corrosion
· Excellent resistance to sulfuric and phosphoric acids
· Good mechanical properties at room temperature and elevated temperatures up to approximately 1000°F (approximately 544°C)
· Suitable for use in pressure vessels with wall temperatures up to 800°F (approximately 484°C)
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of 825 incoloy alloy ship round bars in China. If you're going to wholesale high quality 825 incoloy alloy ship round bars made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
825 Incoloy Alloy Ship Round Bars Description
Incoloy 825 alloy is a nickel-iron-chromium alloy with added molybdenum and copper. It is renowned for its excellent corrosion resistance, particularly in reducing and oxidizing environments. This makes it an ideal material for shipbuilding rebar, which is exposed to the harsh marine environment. The alloy's excellent resistance to crevice corrosion, pitting, and stress corrosion cracking, along with good mechanical strength and weldability, further enhance its suitability for marine applications.
Alloy 825 Round Bar Size Chart
| Dia (in) | Weight per metre (kg) |
Dia (in) | Weight per metre (kg) |
|---|---|---|---|
| 3" | 36.00 | 6 1/2" | 172.00 |
| 3 1/4" | 42.90 | 7" | 199.00 |
| 31/2" | 49.80 | 7 1/2" | 229.00 |
| 3 3/4" | 57.10 | 8" | 260.00 |
| 4" | 65.00 | 8 1/2" | 294.00 |
| 4 1/4" | 73.40 | 9" | 329.00 |
| 4 1/2" | 82.30 | 10" | 406.00 |
| 5" | 102.00 | 11" | 492.00 |
| 5 1/4" | 111.98 | 12" | 585.00 |
| 5 1/2" | 123.00 | 340mm | 728.00 |
| 5 3/4" | 134.00 | 16" | 1040.00 |
| 6" | 146.00 |
825 Incoloy Alloy Ship Round Bars specifications
Chemical Compatibility Chart of Inconel 825 Round Bar
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
825 Incoloy Round Bar finishes
| CD | Cold drawn | P | Polished |
| BD | Bright drawn | SRE | Slit rolled edge |
| CG | Centreless ground | HF | Hot finished |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| ST | Smooth turned | PR | Peeled and reeled |
Incoloy N08825 Round Bar Mechanical & Physical Properties
| Element | Alloy 825 |
| Density | 8.14 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 32,000 , MPa –220 |
| Elongation | 30 % |
Incoloy Alloy 825 Ship Round Bars production process
Gnee Steel offers the following heat treatments for 825 Incoloy Alloy Ship Round Bars: annealing and solution + aging. Gnee Steel also offers hot working and cold working, namely hot rolling and cold drawing.
Raw Material Selection & Melting
High‑purity nickel, chromium, iron and alloying elements are adopted. Melting uses VIM or EAF; VIM avoids air contamination, while EAF supports flexible alloy composition adjustment.
Refining and Casting
Molten metal is refined to remove unwanted impurities and hit target chemistry. Qualified melt is cast into solid ingots, which act as base feedstock for subsequent hot‑working procedures.
Hot Working: Forging & Rolling
Solid ingots go through high‑temperature forging and rolling. Forging refines grain structure to boost strength‑toughness; rolling shapes workpieces into target bar cross‑section dimensions.
Heat Treatment
Solution annealing is the key heat‑treatment for UNS N08825. Heated and rapidly cooled to suppress harmful phases, it maintains corrosion resistance and optimizes tensile, hardness and creep properties.
Machining
Alloy 825 features high strength and work‑hardening tendency. Advanced cutting tools perform turning, grinding and other operations to deliver bars with precise size and qualified surface finish.
Quality Control & Testing
Each batch undergoes full inspection: chemical analysis, tensile & hardness mechanical tests, plus UT and RT NDE. It verifies composition, mechanical performance and internal defect‑free condition.
About Gnee Steel
Gnee Steel is a supplier of 825 Incoloy Alloy Ship Round Bars. Our product offerings include seamless pipes (sizes: 4-219 mm, thicknesses: 0.5-20 mm); welded pipes (sizes: 5.0-1219.2 mm, thicknesses: 0.5-20 mm); plates (sizes: 0.1-100 mm, widths: 10-2500 mm); strip; alloy round bars (sizes: 3-800 mm, diameters: 3-800 mm); flat bars (sizes: 2-100 mm, thicknesses: 10-500 mm); hexagonal bars (sizes: 2-100 mm); wire rod; and extruded sections. We partner with steel mills to provide our customers with 625 alloy that meets or exceeds numerous leading industry standards, including ASTM, ASME, SAE, AMS, ISO, DIN, EN, and BS. Gnee Steel stocks and sells 825 Incoloy Alloy Ship Round Bars, pipes, tubes, plates, strips, sheets, round bars, flat bars, forging billets, hexagons, wire rods, and extruded shapes. Feel free to contact us for a quote at ss@gneesteel.com
