UNS N06059 PIPE
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Due to its excellent resistance to high temperatures and corrosion, UNS N06059 is widely used in the manufacture of equipment and components for high temperature and corrosive environments, such as aerospace, energy, semiconductor, nuclear power and chemical industries. In the aerospace field, it is used to manufacture parts such as combustion chambers and turbine components that need to work at extremely high temperatures. In the chemical processing industry, the corrosion resistance of this alloy makes it an ideal material for handling corrosive chemicals.
Comparison with other alloys
Compared with other nickel-based alloys such as Inconel 625, UNS N06059 is superior in oxidation resistance, but may be slightly inferior in corrosion resistance. Inconel 625 contains higher levels of chromium and molybdenum, which makes it show better corrosion resistance in some reducing environments. However, UNS N06059 provides better performance when facing higher temperature strength and specific types of corrosive environments.
Welding and processing
UNS N06059 has good weldability, but in order to ensure the integrity and performance of the weld, it is usually necessary to use appropriate welding techniques, such as TIG or MIG welding. Heat treatment may be required before and after welding to optimize the microstructure and reduce residual stresses. Additionally, proper surface preparation and cleaning are necessary to maintain the material's optimal performance.
Chemical composition of alloy 59
| C | Si | Mn | P | S | Cr |
| ≤ % | ≤ % | ≤ % | ≤ % | ≤ % | % |
| 0.01 | 0,1 | 0,50 | 0,025 | 0,015 | 22,0-24,0 |
| Mo | Ni | Al | Co | Cu | Fe |
| % | % | % | ≤ % | ≤ % | ≤ % |
| 15,0-16,0 | Rest | 0,10-0,40 | 0,30 | 0,50 | 1,50 |
Characteristics of alloy 59
| Temperature Range | Material for wet corrosion |
| Density | 8,6 g/cm³ |
| ISO-V notch impact toughness | ≥ 225 J/cm² at room temperature |
| ≥ 200 J/cm² bei -196°C | |
| Low sensitivity for intercrystalline corrosion |
Delivery program
| Rods and Bars: | 8 – 85/115sq mm |
| Sheets and Plates: | 2 – 40 mm |
| Coils: | 2 mm |
| Elbows: | OD 48,3 – 88,9 mm |
| Tubes: | OD 10,2 – 273 mm |
