Nickel Iron Chromium Alloy 800HT Description
Incoloy 800HT, also known as Alloy 800HT, N08811 and W.Nr. 1.4959, is a nickel-iron-chromium alloy that offers outstanding strength and excellent resistance to oxidation, carburization and other high temperature corrosion. 800HT nickel-iron-chromium alloy is designed for applications requiring high creep and rupture properties at elevated temperatures.
| Product form | Size range from | Size range to |
| Alloy 800HT pipe | 0.5 in | 8 in |
| Alloy 800HT tube | 12 mm | 260 mm |
| Alloy 800HT pipe fittings | 0.5 in | 8 in |
| Alloy 800HT flanges | 0.5 in | 8 in |
Alloy 800HT Application
1. Industrial furnaces: The alloy is frequently used in industrial furnace applications such as radiant tubes, heat shields and other high temperature furnace components due to its excellent resistance to oxidation and carburization.
2. Petrochemical processing: Incoloy 800HT is widely used in the petrochemical industry, especially for components exposed to high temperatures and corrosive environments, including catalyst mesh supports, furnace walls and related equipment.
3. Heat treatment equipment: The alloy is used in heat treatment equipment where temperature rise and resistance to oxidation and carburization are critical, and is suitable for applications such as trays, baskets and fixtures.
Incoloy Alloy 800HT Specifications
ASTM Specifications
| Alloy | Pipe Smls | Pipe Welded | Tube Smls | Tube Welded | Sheet / Plate | Bar | Forging | Fitting |
|---|---|---|---|---|---|---|---|---|
|
Alloy 800HT (UNS N08811) |
B407 |
B154 |
B163 |
B515 |
B409 |
B408 |
B564 |
B366 |
Standard product forms of incoloy 800HT include tube, pipe, plate, strip, plate, round bar, flat bar, forging, hexagonal bar and wire. Please contact us at ss@gneesteel.com for detailed information.
Chemical composition
|
C |
Al |
Si |
S |
Ti |
Cr |
Mn |
Fe |
Ni |
Cu |
|
0.1 max |
0.15 - 0.60 |
1.0 max |
0.015 max |
0.15 - 0.60 |
19.0 - 23.0 |
1.5 max |
39.5 min |
30.0 - 35.0 |
0.75 max |
Mechanical properties
|
Tensile Strength (ksi) |
0.2% Yield Strength (ksi) |
Elongation% in 2 inches |
|
75 |
30 |
30 |
Physical properties
|
|
Units |
Temperature in°C |
|
Density |
7.94 g/cm³ |
Room |
|
Specific Heat |
0.11 Kcal/kg.C |
21° |
|
Melting Range |
1357 - 1385 °C |
- |
|
Modulus of Elasticity |
196.5 KN/mm² |
20° |
|
Electrical Resistivity |
98.9 µΩ.cm |
20° |
|
Coefficient of Expansion |
14.4 µm/m °C |
20 - 100° |
|
Thermal Conductivity |
11.5 W/m -°K |
20° |
alloy 800HT production testing
Corrosion Resistant Incoloy 800HT
incoloy alloy 800HT packing
