Incoloy 800 Round Pipes
Approximate grades: Alloy 800, INCF800 No8800, 0Cr20Ni32AlTi
Certification: ISO9001:2015
Alloy category: Corrosion-resistant alloy
Substrate shape: Axis wire/strip/straight bar
Alloy series: Nickel-chromium-iron alloy
Implementation standard: ASTM B564
Application areas: Petrochemical, energy, industrial
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of incoloy 800 round pipes in China. If you're going to wholesale high quality incoloy 800 round pipes made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
Nickel 800 Alloy Round Pipes Description
Incoloy 800 nickel-based alloy tube, high-performance tube, composed of nickel, iron, chromium and other elements, has excellent corrosion resistance and high temperature strength, good plasticity, easy processing and welding, suitable for chemical industry, shipbuilding and other fields, please pay attention to water quality when using and check regularly.
GNEE's Incoloy 800 tubes include Incoloy 800 hot-rolled tubes and Incoloy 800 cold-drawn tubes, which have excellent oxidation resistance and corrosion resistance and can remain stable at high temperatures up to 1120°F (600°C).
Alloy 800 Pipe Schedule Chart
|
3 1/2" IPS( 4.000"O. D.) |
1/8" IPS(.405"O. D.) |
|---|---|
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 80 |
|
4" IPS(4.500"O. D.) |
1/4" IPS(.540"O. D.) |
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 10, 80 |
|
5" IPS( 5.563"O. D.) |
3/8" IPS(.675"O. D.) |
|
SCH 40, 10, 160, 80, XXH |
SCH 40, 10, 80 |
|
6" IPS(6.625"O. D.) |
1/2" IPS(.840"O. D.) |
|
SCH 10, 5, 80, 40, 160, 120 XXH |
SCH 5, 40, 10, 160, 80, XXH |
|
8 " IPS(8.625"O. D.) |
3/4" IPS(1.050"O. D.) |
|
SCH 10, 5, 80, 40, 160, 120 XXH |
SCH 40, 10, 160, 80, XXH |
|
10" IPS(10.750"O. D.) |
1" IPS:(1.315′O. D.) |
|
SCH 10, 20, TRUE 80(.500), 40, 80 (.500), |
SCH 5, 40, 10, 160, 80, XXH |
|
12" IPS(12.750"O. D.) |
1-1/4" IPS(1.660"O. D.) |
|
SCH 10, 20, TRUE40(.406), 40(.375), SCH80(.500) |
SCH 40, 10, 160, 80, XXH |
|
14" IPS(14.000"O. D.) |
1-1/2" IPS(1.900"O. D.) |
|
SCH10(.188), SCH40(.375) |
SCH 40, 10, 160, 80, XXH |
|
16" IPS(16.000"O. D.) |
2" IPS(2.375"O. D.) |
|
SCH10(.188), SCH40(.375) |
SCH 40, 10, 160, 80, XXH |
|
18" IPS (18.000"O. D.) |
2 1/2" IPS(2.875"O. D.) |
|
SCH-40 (.375) |
SCH 40, 10, 160, 80, XXH |
|
3" IPS( 3.500"O. D.) |
|
|
SCH 5, 40, 10, 160, 80, XXH |
Nickel Based 800 Alloy Specification
Incoloy 800 Chemical Composition
|
Grade |
C |
Ni |
Cr |
Fe |
Al + Ti |
Mn |
Si |
|---|---|---|---|---|---|---|---|
|
Incoloy 800 |
0.10 max |
30.0-35.0 |
19.0-23.0 |
39.5 min |
0.15-0.60 |
1.5 max |
1.0 max |
Mechanical Properties of Inconel 800H Pipes
| Property | Value |
|---|---|
| Tensile Strength | 520 MPa (75,000 psi) |
| Yield Strength (0.2%) | 205 MPa (30,000 psi) |
| Elongation | 30% |
Incoloy 800 Pipe Pressure Rating
|
OD (in) |
Wall: 0.035" |
Wall: 0.049" |
Wall: 0.065" |
Wall: 0.083" |
|---|---|---|---|---|
|
1/4" |
4,800 |
7,000 |
9,500 |
- |
|
3/8" |
3,100 |
4,400 |
6,100 |
- |
|
1/2" |
2,300 |
3,200 |
4,400 |
- |
|
3/4" |
- |
2,200 |
3,000 |
4,000 |
|
1" |
- |
- |
2,200 |
2,900 |
Incoloy 800 Pipe Weight Chart
|
NPS (in) |
OD (mm) |
Sch 40 Weight ( |
Sch 80 Weight ( |
|---|---|---|---|
|
1/2" |
21.3 |
1.27 |
1.62 |
|
3/4" |
26.7 |
1.69 |
2.20 |
|
1" |
33.4 |
2.50 |
3.24 |
|
1 1/2" |
48.3 |
4.05 |
5.41 |
|
2" |
60.3 |
5.44 |
7.48 |
|
3" |
88.9 |
11.29 |
15.27 |
|
4" |
114.3 |
16.07 |
22.32 |
|
6" |
168.3 |
28.26 |
42.56 |
|
8" |
219.1 |
42.55 |
64.63 |
|
10" |
273.0 |
60.31 |
81.53 |
|
12" |
323.9 |
79.73 |
108.97 |
800 Superalloys Products Display & packing
800 Superalloys Products Display & packing
About Gnee Steel
Gnee Steel is a professional manufacturer of various nickel-based alloys. Gnee Steel's product packaging includes steel strapping: pipes with an outer diameter of no more than 3 inches are usually strapped together with polypropylene film to prevent rust during sea transportation, and then fixed with steel straps; wooden boxes/crates: pipes are usually packaged in wooden boxes or crates to protect them during transportation, especially pipes with longer lengths or larger diameters; airworthy export packaging: suppliers usually use standard airworthy export packaging methods, which may include various materials and technologies to protect pipes during transportation; rainproof cloth packaging: prevents external rainwater, seawater, etc. from penetrating into the export wooden box packaging during transportation. Gnee Steel specializes in the production and sale of alloy materials. Gnee Steel's products are widely used in aerospace, chemical, electric power, automotive, nuclear energy and other fields, and can provide customized alloy material solutions according to customer needs. If you need to understand the price of alloy materials or provide customized alloy material solutions, please feel free to contact us for a quote at ss@gneesteel.com
