Hastelloy W
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of hastelloy w in China. If you're going to wholesale high quality hastelloy w made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
HASTELLOY® W alloy (UNS N10004) is a solid-solution-strengthened super alloy that was developed primarily as a filler metal for welding of dissimilar alloys. It displays excellent dissimilar welding characteristics, and is widely used for that purpose in the gas turbine and aerospace industries. The properties of dissimilar weld joints made with alloy W are dependents upon the alloys joined, but are generally acceptable for a wide variety of combinations. Alloy W is also used as a wrought alloy for a limited number of ring-type applications in older gas turbine engines. HAYNES® 242® alloy is a more modern alloy, and should be considered as a substitute for alloy W in these ring applications (ask for publication H-3079).
Main Standards
SAE AMS 5786
Bar & Wire
SAE AMS 5755
Bar, Rings and Forgings
AWS A5.14 ERNiMo-3
Filler Metal
Chemical Composition
Data Sheet
Physical Properties
| Density | g/cm3 | 9.00 | |
|---|---|---|---|
| lb/in.3 | 0.325 | ||
| Melting Range | °F | 2350 - 2510 | |
| °C | 1290 - 1375 | ||
Mechanical Properties
| Test Temperature | Yield Strength (0.2% Offset) |
Tensile Strength | Elongation | |||
|---|---|---|---|---|---|---|
| °F | °C | ksi | MPa | ksi | MPa | % |
| RT | RT | 75.5 | 520 | 139.8 | 965 | 51 |
| 1000 | 538 | 54 | 370 | 120.8 | 835 | 52.5 |
| 1200 | 649 | 52.9 | 365 | 103.5 | 715 | 27 |
| 1400 | 760 | 55.5 | 385 | 88.5 | 610 | 20.3 |
| 1600 | 871 | 48.8 | 335 | 60.5 | 415 | 31.8 |
| 1800 | 982 | 23.6 | 165 | 32.4 | 225 | 47.5 |
| 2000 | 1093 | 10.6 | 73 | 17.4 | 120 | 79 |
FAQ
Q: What are your company's main products ?
A: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, nickel alloys, etc.
Q: How do you control quality ?
A: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.
Q: What are the advantages of your company ?
A: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q: How many coutries you already exported ?
A: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q: Can you provide sample ?
A: Yes. We can provide the small samples in stock for free, as long as you contact us.Customized samples will take about 5-7 days.
Hot Tags: hastelloy w, China hastelloy w suppliers, incoloy pipe stainless, incoloy material pipe alloy, Inconel 718 Bar, high-temperature alloy, Lncoloy 800H, incoloy ss pipe
