J93380 Duplex Steel Tube
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of j93380 duplex steel tube in China. If you're going to wholesale high quality j93380 duplex steel tube made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
J93380 Duplex Steel Tube
Introduction
CD3MWCuN is a duplex stainless steel for severe corrosion environments including seawater conditions. It also has excellent strength. The duplex stainless steel combines the benefits of the austenitic and ferritic phases.
Duplex 4A is a duplex stainless steel containing elements like cobalt, chromium, and nickel. It combines features of both austenitic and ferritic stainless steels, offering higher strength and corrosion resistance, particularly in chloride-containing environments.
Duplex Stainless CD3MWCuN Applications
- Desalination,
- Pulp & paper, marine,
- Oil & gas,
- Mining, and chemical processing applications.
CD3MWCuN Standards
Cast UNS: J93380
Wrought UNS: S32760
Wrought Grade: ZERON 100
Cast Grade: CD3MWCuN, 6A
Cast ASTM: A890, A995
Duplex Stainless CD3MWCuN Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | |
| CD3MWCuN | Min
Max |
-
0.030 |
1.00
2.00 |
1.0
2.00 |
-
0.030 |
-
0.030 |
24.0
26.5 |
3.00
4.00 |
6.5
8.5 |
Duplex Stainless CD3MN Mechanical Properties
| Yield strength (Rp0.2 / MPa) | ≥450 |
| Tensile strength (Rm / MPa) | ≥700 |
| Fatigue Strength | 370 |
| Elongation (A / %) | 25 |
| Density | 7.8 g/cm³ |
| Shear Modulus | 80 |
Available Sizes And Specifications
| CD3MWCuN stainless steel profile sizes and specifications | |
| Grade | CD3MWCuN |
| Specification | EN, DIN, JIS, ASTM, BS, ASME, AISI, ISO |
| Stainless steel seamless pipe | Outside diameter: 4.0 - 1219mm, Thickness: 0.5 -100mm,Length: 24000mm |
| Stainless steel welded pipe | Outside diameter: 6.0 - 2800mm, Thickness: 0.3 -45mm,Length: 18000mm |
| Stainless steel capillary pipe | Outside diameter: 0.4 - 16.0mm, Thickness: 0.1 -2.0mm,Length: 18000mm |
| Stainless steel seamless sanitary pipe | Outside diameter: 6.0- 219mm, Thickness: 1.0 -6.0mm |
| Stainless steel square pipe | Side Length: 4*4 - 300*300mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel rectangular pipe | Side Length: 4*6 - 200*400mm, Thickness: 0.25 - 8.0mm, Length: 18000mm |
| Stainless steel coil pipe | Outside diameter: 0.4 - 16mm, Thickness: 0.1 - 2.11mm |
| Standard | ASTM A240/A480, ASTM B688, ASTM B463/SB463, ASTM B168/SB168, ASTM B443/SB443/B424/SB424B625/SB625 B575/SB575, JIS G4303, BS 1449, DN17441, G4305 |
Casting Methods in Casting Quality Industrial:
Sand Casting
Investment Casting (Lost Wax Casting, Precision Casting)
CD3MWCuN,6A (UNS J93380) Equivalent Stainless Steel Grade:
ASTM A789 /ASTM A790/ASTM A276: Wrought UNs S32760;
ASTM A182 F55
