Inconel 601 Alloy Square Bar
Shape: Square
Piece length: 6 m
Material grade: 601
Surface finish: Polished
Use/application: Industrial
Alloy type: Inconel
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Ni 601 Alloy Square Bar introduce
GNEE Inconel 601 Alloy Square Bar
Inconel 601 Square Bar is a good oxidation resistant nickel-chromium alloy with high temperature resistance and good strength in carburizing and chloride treatment. These Inconel 601 Square Bars that meet ASTM B166 standards will form a dense, passive and stable oxide layer during heating, which protects the outside from further oxidation. Due to its excellent high temperature oxidation resistance, Inconel 601 Square Bars still maintain extremely high stability at 2200 degrees Fahrenheit (about 1177 degrees Celsius) and are not easily oxidized during heating.
Sizes and Weight of Inconel 600 Square Bars
|
SQUARES |
||
|
Size(mm) |
WT PER FEET IN KGS |
WT PER MTR IN KGS |
|
16 |
0.62 |
2.05 |
|
18 |
0.79 |
2.59 |
|
20 |
0.76 |
2.49 |
|
22 |
1.18 |
3.87 |
|
25 |
1.52 |
5.00 |
|
28 |
1.91 |
6.27 |
|
30 |
2.19 |
7.20 |
|
32 |
2.50 |
8.19 |
|
36 |
3.16 |
10.37 |
|
38 |
3.52 |
11.55 |
|
40 |
3.90 |
12.80 |
|
45 |
4.94 |
16.20 |
|
50 |
6.10 |
20.00 |
|
56 |
7.65 |
25.08 |
|
60 |
– |
– |
|
65 |
– |
– |
|
70 |
– |
– |
|
75 |
– |
– |
|
80 |
– |
– |
|
90 |
– |
– |
|
100 |
– |
– |
Alloy Inconel 601 Square Bar Specification
Nickel 601 Square Bar Composition
| Element | Content |
|---|---|
| S | ≤ 0.015% |
| C | ≤ 0.10% |
| Al | 1.00% ~ 1.70% |
| Fe | 7.7% ~ 17.4% |
| Si | ≤ 0.50% |
| Mn | ≤ 1.00% |
| Cu | ≤ 1.00% |
| Ni | 58.0% ~ 63.0% |
| Cr | 21.0% ~ 25.0% |
MECHANICAL PROPERTIES OF INCONEL ALLOY 601 Square BARS
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) |
Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Cold-worked (annealed) or hot-worked (annealed) / All sizes | 550 | 205 | 30 | ... | ... |
Nickel Based 601 Alloy Square Bar Available Surface Treatments
Nickel 601 Alloy Square Bar production process
Inconel 601 Alloy Square Bar Testing And Qualification Certificate
GNEE Group Inconel 601 Alloy Square Bar Testing And Qualification Certificate
About Gnee Steel
Gnee Steel is a supplier of Inconel 601 Alloy Square Bar, covering tubes: Seamless tubes: Size: 4 - 219 mm; Thickness: 0.5 - 20 mm; Welded tubes: Size: 5.0 - 1219.2 mm; Thickness: 0.5 - 20 mm, Plates: Plate thickness 0.1 to 100 mm; Plate width 10-2500 mm, Strips, Alloy Round Bar Size: Diameter 3-800 mm;, Flat Bar Size: Thickness 2-100 mm; Width: 10-500 mm, Hexagonal Bar Size: 2-100 mm;, Wire and Extruded Profiles. We work with steel mills to provide customers with 625 alloy that meets or exceeds many leading industry standards, including ASTM, ASME, SAE, AMS, ISO, DIN, EN and BS standards.
Gnee Steel stocks and sells Inconel 601 Alloy Square Bar, Tube, Pipe, Plate, Strip, Plate, Round Bar, Flat Bar, Forged Billet, Hexagon, Wire and Extruded Profiles. Feel free to contact us for a quote at ss@gneesteel.com
