Stainless Steel 446 Pipes & Tubes
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of stainless steel 446 pipes & tubes in China. If you're going to wholesale high quality stainless steel 446 pipes & tubes made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
Type SS 446 is high chromium ferritic SS material that is usually used in the high-temperature applications that are ranging from 1500 deg F- 2200 deg F. This material is one of the high oxidation resistance steel material in series 400-4xx. Also, it is showing good resistance ability to the cyclic oxidation and that is quite better than other alloying elements. Moreover, this material is the heat-resistant alloy that tolerates molten brass and copper. This material, however, doesn't have excellent high-temperature strength. Nitrogen alloy is further added for the grain refinement.
Our SS 446 Pipes & Tubes are having many excellent properties to offer because of which the demand for it has got greater. Some properties are high tensile strength, perfection in its dimensions, better surface finishes, long lastingness, welding ability, resistance to general corrosion, rust-free body, etc. SS 446 pipes and SS 446 tubes are having an average ability to withstand at the high-temperature applications. Few applications wherein the usability of the same product are seen are like heat exchangers, constructions, oil & gas industry, pulp & paper industry, power generations, specialty chemicals, chemical industry, petrochemicals, pharmaceuticals, etc.
SS 446 Pipes & Tubes are well tested and then supplied to their respective clients. The tests that are efficiently performed on it are toughness tests, pitting corrosion tests, mechanical tests, etc. The same is packed using wooden boxes for damage-free delivery to the respective clients.
446 STAINLESS STEEL PIPES AND TUBES EQUIVALENT GRADES
| STANDARD | UNS | WNR. | EN | JIS |
|---|---|---|---|---|
| SS 446 | S44600 | 1.4762 | X10CrAlSi25 | SUS 446 |
Stainless Steel Pipe Specification : ASTM A312, A358 / ASME SA312, SA358
SS Tube Specification : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Pipe Size : 1/8" NB to 24" NB, 1/4" OD to 24" OD sizes.
Tube Size : 1/2" OD to 8" OD.
Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Outside Finish : 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
CHEMICAL COMPOSITION OF STAINLESS STEEL 446 SEAMLESS PIPES AND TUBES
| Grade | C | Mn | Si | P | S | Cr | Ni |
|---|---|---|---|---|---|---|---|
| 446 | 0.20 max | 1.50 max | 1.0 max | 0.040 max | 0.030 max | min: 23.0 max: 27.0 |
0.25 max |
MECHANICAL PROPERTIES OF STAINLESS STEEL 446 SEAMLESS PIPES AND TUBES
| Grade | Tensile Strength ksi (MPa) min | Yield Strength 0.2% offset ksi (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 446 | 550 | 345 | 20 | 159 | 51.1 |
PHYSICAL PROPERTIES OF 446 STAINLESS STEEL PIPES AND TUBES
| Grade | Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
|---|---|---|---|---|---|---|---|
| 446 | 0.282 | 150 | 1.1 | 29000 ksi | 5.78 | 500J/kg |
Hot Tags: stainless steel 446 pipes & tubes, China stainless steel 446 pipes & tubes suppliers, nickel based alloy, , , ,
