2507 2205 Super Stainless Steel
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
2507 2205 Super Stainless Steel Supplier
Forms of Super Duplex 2507 2205 Available at GNEE
- Sheet
- Plate
- Bar
- Pipe & Tube (welded & seamless)
- Fittings
- Elbows, tees, stub-ends, returns, caps, crosses, reducers, pipe nipples, etc.
- Weld Wire AWS ER2594, E2594-16, E2553T-1
Super Duplex 2507
- UNS S32750, F53
- ASTM A 240, A790, A815, A182, A 276, A 476, A789
- EN 1.4410
Available thicknesses for Alloy 2507:
| 3/16" | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | 1" | 1 1/4" |
|---|---|---|---|---|---|---|---|---|
| 4.8mm | 6.3mm | 7.9mm | 9.5mm | 12.7mm | 15.9mm | 19mm | 25.4mm | 31.8mm |
| 1 1/2" | 1 5/8" | 1 3/4" | 2" | 2 1/4" | 2 1/2" | 2 3/4" | 3" | |
| 38.1mm | 41.3mm | 44.5mm | 50.8mm | 57.2mm | 63.5mm | 69.9mm | 76.2mm | |
2507 Duplex Stainless Steel Chemical Composition, %
| Cr | Ni | Mo | C | N | Mn | Si | Cu | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|
|
24.0-26.0 |
6.0-8.0 |
3.0-5.0 |
0.030 Max |
.24-.32 |
1.20 Max |
0.80 Max |
0.50 Max |
0.035 Max |
0.020 Max |
Balance |
Mechanical Properties
Specified Tensile Properties, Plate ASTM A240
| Ultimate Tensile Strength, ksi | Minimum .2% Yield Strength, ksi Minimum | % Elongation Min. | Hardness (HRB) Max. |
|---|---|---|---|
|
116 |
80 |
15 |
310 |
Duplex 2205 Chemical Composition, %
| Cr | Ni | Mo | C | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|
|
22.0-23.0 |
4.50-6.50 |
3.00-3.50 |
.030 Max |
0.14-0.20 |
2.00 Max |
1.00 Max |
.030 Max |
.020 Max |
Balance |
ASTM Specifications
| Pipe Smls | Pipe Welded | Tube Smls | Tube Welded | Sheet/Plate | Bar | Flanges, Fittings & Valves |
|---|---|---|---|---|---|---|
|
A790 |
A790 |
A789 |
A789 |
A240 |
A276 |
A182 |
Mechanical Properties
Specified Tensile Properties ASTM A240
| Ultimate Tensile Strength, ksi Minimum | .2% Yield Strength, ksi Minimum | Hardness Max. |
|---|---|---|
|
95 |
65 |
31 Rockwell C |
2507 2205 Super Stainless Steel testing
All our Super Alloy, Nickel Base Alloy, Super Stainless Steel, Incoloy, Inconel, Hastelloy, Monel Alloy Tubes, Plates, Coils, etc. are strictly inspected before shipment.
Customer Visit
GNEE Exhibition
GNEE Steel Group Product Packing & Shipping
Standard Waterproof Packing For Export (or according to client's requirement)
FAQ
Q: What are your company's main products?
A: Our main products are super stainless steel, nickel-based alloy, Monel alloy, Incoloy, Inconel alloy, Hastelloy, super alloy, nickel alloy, etc.
Q: How do you control the quality?
Answer: Factory testing and certification are provided when shipped, and third-party inspection is available. We are also certified by ISO, SGS, Alibaba.
Q: What are the advantages of your company?
A: We have many professionals, technicians, more competitive prices and the best after-sales service than other stainless steel companies.
Q: How many countries have you exported to?
A: Exported to more than 150 countries, mainly from the United States, Russia, the United Kingdom, Kuwait, Egypt, Turkey, Jordan, India, etc.
Q: Can you provide samples?
Answer: Yes. As long as you contact us, we can provide free small samples in stock. Customized samples will take about 5-7 days.
Q: How long is your delivery time?
A: Products will be delivered as soon as possible on the basis of quality assurance. Generally speaking, the delivery time for sample order is
6-10 days. It takes about 15-20 days for container orders.
Q:About Super stainless steel product prices?
A:Prices vary from period to period due to cyclical changes in the price of raw materials.
