Monel 400 Nickel Based Alloy Plate
Thickness: 0.1 to 5.0 mm
Width: 0.5 to 1.0 m
Length: 0.7 to 6.0 m
As a leading supplier and manufacturer in China, GNEE Steel provides cost-effective nickel-based alloy products.
- Send E-mail: ss@gneesteel.com
- Tel: +8615824687445
Gnee Super Alloy (Tianjin) Co., Ltd. is one of the most professional manufacturers and suppliers of monel 400 nickel based alloy plate in China. If you're going to wholesale high quality monel 400 nickel based alloy plate made in China, welcome to get free sample from our factory. Good service and reasonable price are available.
Monel 400 Nickel Alloy Plate introduce
400 Nickel Based Alloy Plate
Gnee Steel offers various Monel 400 sheets as per customer requirements. Monel is based on copper (20-29%) and nickel (65-70%) and also contains manganese and iron (5%) along with other compounds. They are widely used in different application industries like chemicals, fats and fertilizers, shipyards, sugar mills and breweries, paper industry, cement industry etc. Monel 400 sheets are also available in custom made to order lengths and can also be machined or fabricated to meet your requirements for piping systems. Monel 400 sheets are available in thicknesses ranging from 0.018 to 0.140 inches.
Monel 400 is a nickel-copper alloy that is hardened only by cold working. Monel 400 has a low corrosion rate in flowing seawater and hence is widely used in marine applications. Monel 400 also has excellent resistance to stress corrosion cracking in most fresh waters. Monel 400 can be used in temperatures up to 1000 ºF. The alloy has excellent mechanical properties in sub-zero temperatures.
Monel 400 Sheet & Plate Specification :
| Specifications | : | ASTM B127 / ASME SB127, AMS 4544 |
|---|---|---|
| Dimensions | : | ASTM, ASME, and API |
| Thickness | : | Ranging from 0.3mm to 20mm |
| Length | : | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Width | : | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Equivalent Grades For Monel Alloy 400 Sheets & Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Chemical Composition of Monel 400 Sheets and Plates
| Grades | C | Mn | Si | S | Cu | Fe | Ni |
| 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
GNEE Group Factory Environment
Monel 400 Alloy Plate
GNEE Company Environment
Monel 400 Plate
FAQ
Q1:Is it possible to send samples?
Of course, we offer free samples and express shipping to customers all over the world.
Q2:Do you offer a service for customized products?
Yes, we can produce according to your specifications and drawings.
Q3:Can I pay you a visit at your factory?
Customers from all around the world are welcome to visit our factory.
